Chapter 8 The Status Screens
V300 Series User’s Guide
94
Each field is described in the following table.
Table 22 VoIP Statistics
LABEL DESCRIPTION
SIP Status
Account This column displays each SIP account in the V300.
Registration This field displays the current registration status of the SIP account. You
can change this in the Status screen.
• Registered - The SIP account is registered with a SIP server.
• Unregister - The SIP account has failed to register with a SIP
server, or is not active.
Last
Registration
This field displays the last time you successfully registered the SIP
account. It displays N/A if you never successfully registered this
account.
URI This field displays the account number and service domain of the SIP
account. You can change these in VoIP > SIP > SIP Settings.
Protocol This field displays the transport protocol the SIP account uses. SIP
accounts always use UDP.
Message
Waiting
This field indicates whether or not there are any messages waiting for
the SIP account.
Last
Incoming
Number
This field displays the last number that called the SIP account. It
displays N/A if no number has ever dialed the SIP account.
Last
Outgoing
Number
This field displays the last number the SIP account called. It displays N/
A if the SIP account has never dialed a number.
Call Statistics
Call This field displays the V300’s line number.
Peer Number This field displays the SIP number of the person on the other end of the
line, when a call is in progress.
Status This field indicates whether the line is active or not.
• Idle - The line is not active.
• Dial - the line is active and a connection to a SIP server has been
made, but a call is not in progress.
• Dialing - the V300 is initiating a call on this line.
• Ringing - the V300 has initiated a call, and the phone at the other
end is ringing.
• Connected - a call is in progress on this line.
• Disconnect - the line is active, but the connection with the SIP
server has been terminated.
• Hold - a call on this line is on hold.
• Waiting - another line is active, and this line has an incoming call
that has not been answered.
• Transfer - a call on this line is waiting to be transferred.
• Transferred - a call on this line has been transferred to another
number, and is still ongoing.
• Incoming - an incoming call on this line is waiting to be answered.
• Busy - the V300 has tried to initiate a call, but the phone at the
other end is engaged.
