Chapter 3 Using the LCD Screen
V300 Series User’s Guide
47
The following table shows the numbers, letters and symbols you can enter.
3.5 LCD Menu Overview
This section shows the LCD menus, and describes what you can do with each.
Press the Navigator up or down to access the V300’s LCD menu system.
Table 6 Keypad Characters
MODE
Numbe
r
Uppercas
e
Lowercase Symbol
KEY
1 1 [NONE] [NONE] ! | #
22 A B C a b c : ; “
3 3D E Fd e f / \ ?
4 4 G H I g h i @ % &
5 5 J K L j k l . ‘ ,
6 6 M N O m n o + ^ =
7 7 P Q R S p q r s ~ - _
8 8 T U V t u v ( )
9 9 W X Y Z w x y z < >
* . .. $ *
0 0 [NONE] [NONE] [SPACE]
# [CYCLE MODE]
Table 7 LCD Menu Overview
MENU DESCRIPTION
Phonebook Use this menu to view details of your contacts.
Vol Setting
[Volume
Setting]
Speaker Volume Use this menu to set the loudness of the internal
speaker.
Phone Volume Use this menu to set the loudness of the V300’s
handset.
Ring Volume Use this menu to set the loudness of the V300’s
ringtone.
Headset Volume Use this menu to set the loudness of an external
headset you plug into the V300.
