Konica Minolta bizhub PRO 920 [127/980] Troubleshooting
![Konica Minolta bizhub PRO 920 [127/980] Troubleshooting](/views2/1122005/page127/bg7f.png)
Troubleshooting
5
bizhub PRO 920 5-15
ADF
Finisher (with Punch Kit)
Z Folding Unit
Case Checkpoint Remedy
ADF cannot be used af-
ter [Reset] is pressed.
Is ADF slightly open? Fully close the ADF.
Is ADF selected in the initial
setting?
Set to use ADF in the initial setting.
See p. 15-3.
Original paper cannot be
fed.
Is ADF slightly open? Fully close the ADF.
Does the original type con-
form to the specifications?
Change the original paper to any of
the recommended size and weight.
Are originals correctly load-
ed?
Position originals properly in the
ADF.
Case Checkpoint Remedy
Finisher does not oper-
ate.
Is any mishandled paper left
inside the Finisher?
Check for a paper misfeed and re-
move it, as required.
Is Finisher door slightly open? Securely close the Finisher door.
Staples are incorrectly
positioned (rotated by 90
degrees) in copies.
Is Rotation function activat-
ed?
Reload copy paper in appropriate
direction. (See page 11-67.)
Copies skew in the out-
put sets and cannot be
stapled or punched in
position.
Is copy paper excessively
curled?
Reload the paper upside down into
the tray.
Is there any gap found be-
tween side guide plates (or
paper guides when using
Multi-sheet bypass tray) and
copy paper in the selected
tray?
Make sure the side guide plates (or
paper guides) are securely aligned
to the copy paper in the tray to be
used.
Using Punch mode, cop-
ies cannot be punched.
Is the message "Waste bas-
ket of Punch kit is full" dis-
played?
Empty the waste basket.
Case Checkpoint Remedy
Copies skew in the out-
put sets and cannot be
punched in position.
Is copy paper excessively
curled?
Reload the paper upside down into
the tray.
Is there any gap found be-
tween side guide plates (or
paper guides when using
Multi-sheet bypass tray) and
copy paper in the selected
tray?
Make sure the side guide plates (or
paper guides) are securely aligned
to the copy paper in the tray to be
used.
