4-14 bizhub PRO 920

4.3 Adding Toner

When toner supply becomes low, the message "Please add toner" appears

on the Basic Screen, and the toner supply icon ( ) keeps prompting you

till the toner bottle is replaced.

Reminder

Use the same number toner bottle as described on the label applied on

the front of the toner unit. Otherwise, machine trouble may occur.

7 CAUTION

Keep the toner bottle away from the children.

% The toner is non-toxic; however if you inhale or contact with eyes by

accident, flush with water and seek medical advice.

7 WARNING

Do not throw the empty toner bottle into a fire.

% If it is thrown into a fire, the toner may ignite and cause a dangerous

situation.
