Paper and Original Information

bizhub PRO 920 3-3

3 Paper and Original Information

3.1 Paper Information

This machine is equipped with the following trays for loading copy paper.

- Trays 1, 2, and 3 (Main body trays)

- Tray 4 (Large capacity unit LU-403/404)

- Multi-sheet bypass tray

Also, the following equipment is provided for

conveying/processing/delivering copies.

- ADU (Automatic Duplex Unit)

- Finisher (FS-509/FS-604)

- Post inserter (PI-501)

- Punch kit (PK-504/505)

- Z folding unit (ZU-601/602)

- Trimmer unit (TU-501)
