Konica Minolta bizhub PRO 920 [55/980] Z folding unit zu 601 602

Preparation for Use

bizhub PRO 920 2-19

Z Folding Unit ZU-601/602

No. Name Description

1 Z folding unit front door Opens to allow removal of mishandled paper or

waste paper punched out.

2 Inlet lever Opens to allow removal of mishandled paper.

3 Knob Turned to ease removal of mishandled paper.

4 Handle Can be withdrawn to allow removal of mishandled

paper.

5 Outlet lever Opens to allow removal of mishandled paper.

6 Waste basket Holds waste paper punched out and withdrawn for

removal of waste paper.
