Specifications
7
bizhub PRO 920 7-9
Trimmer Unit TU-501
Accessories:
- Expanded Memory Unit EM-701
- Image Controller IC-203
- PostScript Kit PS-503
- Mount Kit MK-707
These specifications are subject to change without notice.
Fold types Z-fold, Half fold (8.5"×14" only)
Fold position (width from the
edge to the first fold)
A3: 209 mm or less
B4: 181 mm or less
11 ×17": 215 mm or less
8.5"×14": 241.7 mm or less
Paper type in Z-Fold mode Plain paper: 60 to 90 g/m
2
Paper sizes in Z-Fold mode ZU-601: A3, B4
ZU-602: A3, B4, 11"×17", 8.5"×14"
Paper sizes other than listed above will be output without any
fold.
Dimensions 169 (W) × 660 (D) × 930 (H) mm
Weight Approx. 38 kg
Power source Supplied from an outlet
Specifications
Specifications
Function Trimming the end of booklet
Trimming width 10 mm or less
Number of trimmed sheets 40 sheets max. (80 g/m
2
paper) in Fold&Staple mode (20-
sheet-folded booklet or 19-sheet-folded booklet with 200
g/m
2
paper cover)
6 sheets max. (80 g/m
2
paper) in Half Fold mode (3-sheet-
folded booklet)
Paper types Plain/Recycled paper: 60 to 90 g/m
2
Paper sizes A3, B4, A4R, 11"×17", 8.5"×14", 8.5"×11"R, Wide sizes (max.
314 × 460 mm)
Dimensions 1,144 (W) × 604 (D) × 562 (H) mm
Weight Approx. 68 kg
Power source Supplied from an outlet
