2
Preparation for Use
2-26 bizhub PRO 920
Low Power
This function conserves energy by lowering the power consumption to
228.6W or less in standby mode.
Low Power activates automatically after a specified period (initially 15
minutes) of copier inactivity with the Power Save LED lit, touch panel gone
off, and all other LEDs except Start LED on the control panel turned off. The
Start LED will turn orange, while the Main Power indicator keeps green.
To start a copying job, press any key on the control panel or touch panel.
!
Detail
The Low Power function can be set to 5 minutes/ 10 minutes/ 15 minutes/
30 minutes/ 60 minutes/ 120 minutes/ 240 minutes. For details, refer to
"1 Power Save Setting" on page 18-13.
2
Note
If the Sleep function activates at the same time, the power will be turned
off.
The touch panel will not go off during a duplex copying job or when the
Jam Position Screen is displayed.
Sleep
This function achieves further energy conservation by reducing power
consumption to 8.9W or less in standby mode.
In the initial setting, Sleep follows Low Power after a specified period (initially
90 minutes) of copier inactivity, with the Power Save LED lit and all other
LEDs on the control panel and touch panel turned off. The Main Power
indicator keeps green.
To start a copying job, press [Power Save]. The copying operation will
become available.
!
Detail
The Sleep can be set for 30 minutes/ 60 minutes/ 90 minutes/ 120
minutes/ 240 minutes, or can be deactivated. For details, refer to "1
Power Save Setting" on page 18-13.
