Preparation for Use
2
bizhub PRO 920 2-13
Finisher FS-509 (+ Punch Kit PK-504/505)
2
Reminder
The Primary (Main) tray gradually goes down while printed materials
output. DO NOT allow any object to interfere with the operation of the tray
on the left side of the finisher, as any interference may cause damage to
the finisher.
Finisher FS-509
23
1
No. Name Description
1 Finisher door Opens to the internal finisher to allow replenishing
staples and clearing mishandled paper, and also to
allow removal of waste paper punched out when
Punch kit PK-504/505 is installed.
2 Primary (main) tray Holds sets output in the selected finishing mode
other than specified above.
3 Secondary (sub) tray Holds sets output in Sort, Group, Face Up, or Face
Down mode.
