Konica Minolta bizhub PRO 920 [848/980] Ap i f

PageScope Web Connection Setting

20-58 bizhub PRO 920

AP I/F

This screen appears when you click [AP I/F] on the [Network] tab. The screen

is used to enter and confirm settings concerning the AP I/F. Enter for

individual items.

Description

- Enter for individual items.

Port Number, Use SSL/TLS, Port Number (SSL).

- [Apply] button:

Click the button to apply the new settings.

- [Clear] button:

Click the button to clear the settings that were entered.
