PageScope Web Connection Setting
20
bizhub PRO 920 20-7
No. Item Description
1 KONICA MINOLTA PageScope
Web Connection Logo
Click the KONICA MINOLTA logo to jump to the
Konica Minolta web site.
http://konicaminolta.jp
Click the PageScope Web Connection logo to jump
to the About Screen, providing the version informa-
tion and the copyright description.
Click the PageScope Web Connection logo on the
About Screen to jump to the following Web site.
http://pagescope.com
2 Status Display Icons and text indicate the current status of the
main body's printer and scanner. The message
"Ready" appears when the main body's printer and
scanner are operating normally.
3 Tabs Select the categories of items to be displayed.
System
Job (User Mode only)
Print
Scan (Administrator Mode only)
Network (Administrator Mode only)
For the details of each tab, see the following sec-
tions.
4 Help If an online manual URL has been set, the online
manual will appear.
5 Information and Setting Details Displays the details of the selected menu.
6 Menus Selects the information or setup item to be dis-
played. The menus that appear vary depending on
the tab selection.
For the details of each menu, see the following sec-
tions.
7 Administrator Mode Logs into Administrator Mode. (For details on the
login procedure for Administrator Mode, see "Log-
ging in Using Administrator Mode" below.)
8 Language Sets the display language for the browser. [Auto] in-
dicates the same language as the operating system
being userd and the other optinos indicate the same
language as displayed on the control panel.
