2
Preparation for Use
2-4 bizhub PRO 920
No. Item Description
1 ADF (Automatic Document Feed-
er)
Automatically feeds multiple originals one at a time
to the original glass for copying.
2 Sub power switch Turns machine power on/off when pressed.
3 Work table Provides a convenient workspace for documents
both before and after copying.
4 Multi-sheet bypass tray Used for small quantity copying onto plain paper of
other size or type than that loaded in main body
trays, or copying onto special paper.
5 Tray 4 (Large capacity unit LU-
403/ LU-404) (option)
Holds 4,000 sheets (LU-403) / 4,000 sheets (LU-
404) of 80 g/m
2
paper.
6 Right side door Opens to allow removal of mishandled paper.
7 Tray 3 (universal tray) Holds 1,000 sheets (80 g/m
2
paper) from A3 to A5.
8 Tray 2 (universal tray) Holds 500 sheets (80 g/m
2
paper) from A3 to A5.
9 Tray 1 (universal tray) Holds 500 sheets (80 g/m
2
paper) from A3 to A5.
10 Left side door Opens to turn the main power switch on/off, or
opens together with front door to allow removal of
mishandled paper.
11 Front door Opens to allow toner supply or removal of mishan-
dled paper.
12 Z folding unit ZU-601/602 (option) Punches file holes and/or z-folds the output copies.
13 Finisher FS-509/FS-604 (option) Sorts and/or staples copies into finished sets, and
FS-604 also folds or folds & staples copies into
bookletstyled sets.
With optional Punch kit PK-504/505 installed,
Punch mode is also available.
14 Trimmer unit TU-501 (option) Trims the end of booklet.
15 Post inserter PI-501 (option) Used together with FS-509/FS-604, loads cover
sheet paper to feed it as cover, and enables to use
Finisher manually.
16 Touch panel Displays interactive operation screens.
17 Control panel Controls copier operations and displays messages
as required.
