bizhub PRO 920 27-33

TCP/IP Abbreviation of Transmission Control Protocol/Internet Protocol.

Substantially the standard protocol used for the Internet.

Uses IP address to identify each network device.

TIFF Abbreviation of Tagged Image File Format.

One of the file formats to save image data (extension; .tif).

Various types of image information can be saved in one image data

with the “tag” representing the data type.

Web browser Software to access web pages. Internet Explorer, Netscape Naviga-

tor, etc. are examples.

Button Function
