![Konica Minolta bizhub PRO 920 [44/980] Caution](/views2/1122005/page44/bg2c.png)
2
Preparation for Use
2-8 bizhub PRO 920
7 CAUTION
The touch panel of the control panel is covered with glass.
% Do not drop heavy objects on the glass, or put excess weight or
pressure on it; otherwise the glass may break or scratched and you
may be injured.
7 CAUTION
If the Service Call Screen is displayed, copier operations cannot be
continued any more.
% Stop the operation to prevent any unexpected accident. Write down
the report code, then switch off the machine and disconnect from the
power socket. Contact your service representative and inform them of
the report code.
15 [Utility/Counter] key Displays the Utility Screen or Counter Screen.
16 [Mode Check] key Displays a screen showing all settings that are se-
lected for the current job.
17 Touch panel Displays machine and copying status, help informa-
tion, interactive screens, and touch keys for select-
ing all functions.
18 [Accessibility] key Adjusts the response time when touch panel keys or
control panel keys are pressed.
19 Contrast adjustment dial Can be turned to adjust the brightness of the touch
panel.
20 Power Save LED Lights when any power-saving mode is activated, or
machine power is off due to the timer function.
21 [Power Save] key Enables temporary use of the machine when the
Power Save LED is lit, or activates power-saving
mode for times when the copier is inactive.
22 [Help] key Displays a screen with help for the currently select-
ed function.
No. Name Description
