Controller Setting
16
bizhub PRO 920 16-7
* : For the details of the symbol set, see the appendix.
2 PCL Setting
1 Font Source Select the medium of font source.
Internal: Standard font
Disk: Downloaded font
Soft: Software font
Internal, Disk, Soft
Internal
2 Font Number Specify the area of available font number ac-
cording to the font source.
0 to 999
0
3 Symbol Set Specify the symbol set.*
DESKTOP, ISO4, ISO6, ISO11, ISO15, ISO17,
ISO21, ISO60, ISO69, ISO 8859/Latin 1, ISO
8859/Latin 2, ISO 8859/9 Latin 5, ISO8859/10
Latin 6, ISO 8859/15/Latin 9, Legal, Math-8, MC
Text, Microsoft Publishing, PC-75, PC-8 Code
Page 437, PC-850 Multilingual, PC-852 Latin 2,
PC-858 Multilingual. PC-8 Turkish, PC-8 Dan-
ish/Norwegian, PC-1004, PI Font, PS Math, PS
Text, Roman-8, Windows 3.0 Latin 1, Windows
Baltic, Windows 3.1 Latin 1, Windows 3.1 Latin
2, Windows 3.1 Latin 5, PC-866 Ukraine
Roman-8
4 Form lines Specify the number of lines per page.
5 to 128
64
5 Font point size Specify the font size by point.
0.44 to 99.75
12.00
6 Font pitch Specify the font pitch.
0.44 to 99.95
10.00
7 CR/LF Mapping Select the line feed code.
Off, CR, LF, CRLF
Off
3 PS Setting (Option)
1 Print to PS Error Select to print the error report when an error oc-
curs while rasterizing PostScript data.
Off, On
On
2 PDF -> PS Con-
version error con-
trol
Select to print the error pages produced by the
memory overflow when printing a PDF file.
Off, On
Off
4 TIFF Setting
1 Auto Paper Se-
lect
Select to use APS function.
Off, On
On
2 Image Position Select the image position to be printed on a
page.
Left, Centre
Left
Menu Items Description Default
