18
Utility <Administrator Setting>
18-118 bizhub PRO 920
Specify the settings for third party applications. For details, refer to
page 18-162.
Specify the PSWC (Page Scope Web Connection) setting. For details, refer
to page 18-165.
Specify the Network Setting Clear setting. For details, refer to page 18-167.
Specific setting and Description Default
12 AP I/F
AP I/F
Specify to use AP I/F.
Use/Not Use
Use
AP I/F Over SSL
If SSL is used for PSWC communication, this setting is en-
abled.
Use/Not Use
Not Use
AP I/F Authentication
Enable the setting to block access to this I / F.
On/Off
On
AP I/F Login Name
Required if the AP I/F Authentication is set to [On].
Max. 8 characters combining symbols and alphanumerics
can be used.
- - -
AP I/F Login Password
Required if the AP I/F Authentication is set to [On].
Max. 8 characters combining symbols and alphanumerics
can be used.
- - -
AP I/F Port No.
If SSL is not used, the port number specified in this field
will be used.
1 - 65535
50001
AP I/F Port Number (SSL)
If SSL is used, the port number specified in this field will be
used.
1 - 65535
50003
Specific setting and Description Default
13 PSWC
PSWC
Specify to use the PSWC function.
Use/Not Use
Use
Specific setting and Description Default
14 Network Setting Clear
Initialize Set
Restore the initial network settings specified at the time of
shipment.
- - -
