Specifications
7-4 bizhub PRO 920
ADF
These specifications are subject to change without notice.
Tray capacity Multi-sheet bypass tray: 150 sheets (80 g/m
2
paper)
Main body trays 1 and 2 (universal tray): 500 sheets (80 g/m
2
paper)
Main body trays 3 (universal tray): 1,000 sheets (80 g/m
2
pa-
per)
Warm-up time Approx. 5.5 minutes
First-page copy time Approx. 3.1 seconds (A4)
Sound power level Main body: 78 dB (operating) / 58 dB (standby)
Power requirements AC230V, 15A, 50Hz
Power consumption 3.45 KW or less (with full options)
Weight Approx. 280 kg (Main body + ADF)
Dimensions 887 (W) × 780 (D) × 1,203 (H) mm (Main body + ADF)
3,180 (W) × 780 (D) × 1,203 (H) mm (Main body + ADF + LU-
404 + FS-604 + TU-501)
3,372 (W) × 780 (D) × 1,203 (H) mm (Main body + ADF + LU-
404 + FS-604 + ZU-601/602 + TU-501)
Space requirements 200 mm or more on the back
100 mm or more on both sides
Specifications
Specifications
Name DF-606
Feeding speed Single-sided: 92 sheets/min. (A4)
Double-sided: 65 sheets/min. (A4)
Document types Plain paper, 50 to 130 g/m
2
(50 to 200 g/m
2
using SDF mode for single-sided original)
Document sizes Max. 297 mm × 431.8 mm ~ min. 128 mm × 139.7 mm
Detectable sizes for Auto Paper Select mode: A3, B4, A4,
A4R, B5, B5R, A5, A5R, B6R, 11"×17", 8.5"×11", 8.5"×13"
Available to scan mixed originals of AB sizes and inch sizes
Feeder capacity Max. 100 sheets (80 g/m
2
)
Document insertion Automatic feed
Weight Approx. 22 kg
Dimensions 650 (W) × 570 (D) × 170 (H) mm
Power source Supplied from main body
