Konica Minolta bizhub PRO 920 [131/980] Maintenance

Maintenance

bizhub PRO 920 6-3

6 Maintenance

6.1 Cleaning Image Scanning Section

In order to maintain optimum copy quality, always keep the following areas

clean.

Cleaning the ADF Scanning Glass

Keep the ADF scanning glass clean;

otherwise soil marks may be copied,

resulting in dark lines on the copies.

Raise the document feeder, then clean the

glass with a clean soft cloth.

Reminder

Never use paint solvents, such as

benzene or thinners, to clean the ADF scanning glass.

Cleaning the Original Glass

Raise the document feeder, then clean the

original glass with a clean soft cloth.

The glass may also clean with a soft cloth

dampened slightly with water, if it is

difficult to clean.
