Инструкция по эксплуатации Страница: 52

Konica Minolta bizhub PRO 920 [52/980] 16 bizhub pro 920

Preparation for Use

2-16 bizhub PRO 920

Reminder

The Primary (Main) tray gradually goes down while printed materials

output. DO NOT allow any object to interfere with the operation of the tray

on the left side of the finisher, as any interference may cause damage to

the finisher.

Finisher FS-604

+ Punch Kit PK-504/505

1011

No. Name Description

1 Inlet lever Opens downward to remove mishandled paper.

2 Punch kit (option) Punches file holes in output copies.

3 Cover sheet conveyance lever Opens leftward to remove mishandled paper.

4 Secondary (Sub) tray convey-

ance lever

Opens rightward to remove mishandled paper.

5 Stacker conveyance lever Opens down and leftward to remove mishandled pa-

per.
