Konica Minolta bizhub PRO 920 [76/980] Paper size
![Konica Minolta bizhub PRO 920 [76/980] Paper size](/views2/1122005/page76/bg4c.png)
3
Paper and Original Information
3-8 bizhub PRO 920
Paper Size
Paper trays Available sizes
Tray 1, 2, and 3 (Main body trays) • Standard: A3, B4, A4, A4R, B5, B5R, A5*, 11”×17”,
8.5”×14”, 8.5”×11”, 8.5”×11”R, 5.5”×8.5”
*: Portrait orientation only
• Original Size Detection: Detects 8.5”×11”R instead of
A4R, 5.5”×8.5” instead of A5, and
8”×13”/8.12”×13.2”/8.25”×13”/8.5”×13” instead of
8.5”×14.
• Custom: Max. 314 × 445 mm ~ min. 182 × 140 mm
• Wide Paper: A3W, B4W, A4W, A4WR, B5W, A5W,
11”×17”W, 8.5”×11”W, 8.5”×11”WR, 5.5”×8.5”W
Tray 4 (Large capacity unit LU-403) A4 fixed (can be changed to the following sizes)
• Standard: B5, 8.5”×11”
• Custom: Max. 314 × 223 mm ~ min. 257 × 182 mm
• Wide Paper: A4W, B5W, 8.5”×11”W
Tray 4 (Large capacity unit LU-404) A3 fixed (can be changed to the following sizes)
• Standard: B4, A4, A4R, 11”×17”, 8.5”×14”, 8.5”×11”,
8.5”×11”R
• Custom: Max. 314 × 460 mm ~ min. 257 × 182 mm
• Wide Paper: A3W, B4W, F4W, A4W, A4WR, 11”×17”W,
8.5”×11”W, 8.5”×11”WR
Multi-sheet bypass tray • Standard: A3, B4, A4, A4R, B5, B5R, A5, 11”×17”,
8.5”×14”, 8.5”×11”, 8.5”×11”R, 5.5”×8.5”
• Original Size Detection: Detects 8.5”×11”R instead of
A4R, 5.5”×8.5” instead of A5, and
8”×13”/8.12”×13.2”/8.25”×13”/8.5”×13” instead of
8.5”×14.
• Custom: Max. 314 × 460 mm ~ min. 100 × 148 mm
• Wide Paper: A3W, B4W, A4W, A4WR, B5W, B5WR,
A5W, A5WR, 11”×17”W, 8.5”×11”W, 8.5”×11”WR,
5.5”×8.5”W, 5.5”×8.5WR
Equipment Available sizes
ADU • Standard/Original Size Detection: A3/11”×17” to
A5*/5.5”×8.5”*
*: Portrait orientation only
• Custom: Unavailable
• Wide Paper: A3W/11”×17”W to A5W*/5.5”×8.5”W*
*: Portrait orientation only
Finisher FS-509 Max. 314 × 458 mm ~ min. 100 × 148 mm
Finisher FS-604 Max. 314 × 460 mm ~ min. 100 × 148 mm
(A3, B4, A4R, 8.5”×11” only in Half Fold and Fold&Staple
modes)
