Specifications
7
bizhub PRO 920 7-3
7 Specifications
7.1 Main Body Specifications
Main Body
Specifications
Name bizhub PRO 920
Type Console type
Copying system Laser electrostatic transfer method (dual beam)
Original glass Stationary
Photoconductor OPC
Light source Xenon lamp
Developing method Dry-type dual-component reverse magnetic brush developing
Fixing method Heat roller
Density adjustment Automatic and manual (9 levels), user-set density (2 types)
Magnification ratio 1:1 ± 1.0% or less
Enlargement: ×1.154 (145.4%), ×1.224 (122.4%), ×1.414
(141.4%), ×2.000 (200.0%)
Reduction: ×0.866 (86.6%), ×0.818 (81.8%), ×0.707 (70.7%),
×0.500 (50.0%)
Minimal: ×0.930 (93.0%) (fixed)
XY Zoom (interlocked and individual): 0.250 to 4.000 (25.0% ~
400.0%) (in 0.001 increments)
User-set zoom ratio: 3
Resolution 600 dpi
Copy paper Plain paper: 61 to 90 g/m
2
Thick paper: 91 to 200 g/m
2
Thin paper: 50 to 60 g/m
2
Special paper: OHP transparencies, labels
* Ink-jet paper is unavailable.
Copying speed 92 copies/min. (A4), 73 copies/min. (A4R), 92 copies/min.
(B5), 81 copies/min. (B5R), 55 copies/min. (A3), 62 cop-
ies/min. (B4)
Set quantity 1 to 9999 sheets or 1 to 9999 sets
Memory 256 MB (RAM) + 10 GB (HDD)
Original document Type: Sheets/ books (using original glass)
Size: 303 mm × 460 mm at maximum
Copy size Max. 314 × 460 mm ~ Min. 100 × 148 mm
Image loss: leading and trailing edges 2.0 mm ± 2.0 mm, front
and rear 1.5 mm ± 1.5 mm
