Appendix
27
bizhub PRO 920 27-7
[3] Network
Main menus Sub menus Target items
TCP/IP TCP/IP TCP/IP
Network Speed
Auto IP
IP Adress
Subnet Mask
Default Gateway
Host Name
Domain Name
DNS Server
RAW Port Number1
RAW Port Number2
RAW Port Number3
RAW Port Number4
RAW Port Number5
RAW Port Number6
LPD LPD
IP Address Filtering Access Permission Address
Start address 1 - Ending address 1
Start address 2 - Ending address 2
Start address 3 - Ending address 3
Start address 4 - Ending address 4
Start address 4 - Ending address 5
Access Refusal Address
Start address 1 - Ending address 1
Start address 2 - Ending address 2
Start address 3 - Ending address 3
Start address 4 - Ending address 4
Start address 4 - Ending address 5
NetWare Netware NetWare Print
Frame Type
Mode
PServer
Print Server Name
Print Server Password
Print Queue Scan Rate
Bindery/NDS
Bindery
Preferred File Server
NDS
Preferred NDS Context
Preferred NDS Tree Name
Nprinter/Rprinter
Printer Name
Printer Number
