9
Basic Job Settings
9-16 bizhub PRO 920
Copying Using Special Paper (Bypass Tray Setting)
Use the Multi-sheet bypass tray to copy using the special paper type or size.
The following settings are provided:
- Paper type: - (blank), Normal, Thick, Thin Paper, OHP Paper, Trace, User
- Original Size Detection: Sets the machine to detect a specific paper size
instead of the size normally to be detected; namely, 5.5"×8.5" instead of
A5, 8.5"×11"R instead of A4R, 8"×13"/8.12"×13.2"/8.25"×13"/8.5"×13"
instead of 8.5"×14", and B6R/5.5"×8.5"R instead of A5R.
- Paper size: Standard, Custom, Wide Paper, Tab Paper
!
Detail
Special paper can also be loaded in the main body tray or in the LCU to
use on a regular basis. Refer to "Paper Setting" on page 15-3.
For specifications of special paper to be loaded in the Multi-sheet bypass
tray, see "Special Paper in Multi-Sheet Bypass Tray" on page 3-10.
For details on loading paper in the Multi-sheet bypass tray, see "Loading
Paper in Multi-Sheet Bypass Tray" on page 4-7.
2
Reminder
When setting wide size, be sure to specify the precise dimensions of
paper to be used. The dimensions of the wide size selected on the Wide
Size Paper Screen are not correctly set in the initial setting.
