Konica Minolta bizhub PRO 920 [90/980] Loading paper in lcu lu 403 lu 404

Supplies & Handling

4-8 bizhub PRO 920

Loading Paper in LCU (LU-403/LU-404)

The Large capacity unit can be loaded with only the paper size previously

specified.

0 Be sure that the machine is powered on before loading paper in the LCU.

Without the power turned on, the LCU bottom plate will not function.

1 Open the LCU top door.

2 Press the paper loading button to

lower the LCU bottom plate.

LU-404

LU-403
