Specifications
7-8 bizhub PRO 920
Large Capacity Unit LU-403
Large Capacity Unit LU-404
Z Folding Unit ZU-601/602
Specifications
Function Paper feeding into main body
Paper capacity 4,000 sheets (80 g/m
2
paper)
Paper sizes A4, B5, 8.5"×11", Wide sizes (max. 314 × 223 mm)
Paper types Plain/Recycled paper: 61 to 90 g/m
2
Thick paper: 91 to 200 g/m
2
Thin paper: 50 to 60 g/m
2
Dimensions 430 (W) × 639 (D) × 690 (H) mm
Weight Approx. 30 kg
Power source Supplied from main body
Specifications
Function Paper feeding into main body
Paper capacity 4,000 sheets (80 g/m
2
paper)
Paper sizes A3, B4, A4, A4R, 11"×17", 8.5"×14", 8.5"×11", 8.5"×11"R,
Wide sizes (max. 314 × 460 mm)
Paper types Plain/Recycled paper: 61 to 90 g/m
2
Thick paper: 91 to 200 g/m
2
Thin paper: 50 to 60 g/m
2
Dimensions 670 (W) × 639 (D) × 695 (H) mm
Weight Approx. 42 kg
Power source Supplied from main body
Specifications
Function Punching file holes and Z-folding the output copies
Number of punch holes ZU-601: 4 holes (Swedish type)
ZU-602: 2 or 4 holes
Hole diameter 8.0 ± 0.5 mm
Hole pitch ZU-601: 21 ± 0.5 mm / 70 ± 0.5 mm / 21 ± 0.5 mm
ZU-602: 80 ± 0.5 mm
Paper types in Punch mode Plain paper: 61 to 90 g/m
2
Thick paper: 91 to 170 g/m
2
Thin paper: 50 to 60 g/m
2
Paper sizes in Punch mode ZU-601: A3, B4
ZU-602: A3, B4, A4, A4R, B5, B5R, A5, A5R, 11"×17",
8.5"×14", 8.5"×11", 8.5"×11"R, 5.5"×8.5", 5.5"×8.5"R
