Specifications
7
bizhub PRO 920 7-5
7.2 Option Specifications
Finisher FS-509
*: Effective size (width including Primary (main) tray) will be 668 mm / 825 mm
(with the tray edge extended).
Specifications
Type Stapler finisher
Mountable options: Z folding unit, Punch kit, Post inserter
Exit trays Primary (main) tray
Secondary (sub) tray (for Straight delivery only)
Function Straight delivery: Output sorted/grouped sets normally to the
Primary (main) trayor Secondary (sub) tray.
Offset delivery: Output sorted/grouped sets to the Primary
(main) tray, having each set offset by approx. 30 mm upon ex-
it, having each set offset by approx. 30 mm upon exit.
Staple delivery: Output stapled sets to the Primary (main) tray
Paper types Plain paper: 61 to 90 g/m
2
Thick paper: 91 to 200 g/m
2
Thin paper: 50 to 60 g/m
2
Special paper: OHP transparencies, labels
Paper sizes A3, B4, A4, A4R, B5, B5R, A5, B6, 11"×17", 8.5"×14",
8.5"×11", 8.5"×11"R, 5.5"×8.5", 5.5"×8.5"R
Non-standard sizes can be delivered to the Secondary (sub)
tray only.
Stapler capacity
FS-509
50-sheet staple or 100-sheet staple selectable
100 sheets max. (80 g/m
2
paper) / 50 sheets max. (80 g/m
2
paper)
Staples in cartridge 5,000 staples
Dimensions 442 (W)* × 656 (D) × 990 (H) mm
Weight Approx. 60 kg
Power source Supplied from main body
