Utility <Administrator Setting>
18
bizhub PRO 920 18-119
Specify the LDAP setting. For details, refer to page 18-169.
Specific setting and Description Default
15 LDAP
1 LDAP On/Off Setting
LDAP Function
Select to use or not to use LDAP function.
Use/Not Use
Not Use
Max. Search Results
Specify the maximum number of the address to be
displayed after the search.
5 - 1000
100
Timeout
Specify the maximum duration waiting for the search
result.
5 - 300
60
Initial Setting for Search Details
Specify the initial items for making detailed search.
- - -
2 Setting Up LDAP
Server Address
Specify the LDAP server address.
0.0.0.0
Max. 255 characters combining symbols and alpha-
numerics can be used.
0.0.0.0.
Search Base
Specify the directory path of LDAP server.
Max. 255 characters combining symbols and alpha-
numerics can be used.
- - -
Enable SSL
Select to use SSL when connecting with LDAP serv-
er.
Use/Not Use
Not Use
Port Number
Specify the port number of LDAP server.
The port number varies depending on the Enable
SSL setting.
1 - 65535
389: SSL not used
636: SSL used
General Settings
Select the authentication type to login the LDAP
server.
Anonymous/Simple/Digest-MD5/GSS-SPNEGO
Anonymous
Login Name
Specify a login name.
Max. 255 characters combining symbols and alpha-
numerics can be used.
- - -
Password
Specify a password.
Max. 128 characters combining symbols and alpha-
numerics can be used.
- - -
