3
Paper and Original Information
3-10 bizhub PRO 920
Special Paper in Multi-Sheet Bypass Tray
Multi-sheet bypass tray accepts the following special paper type that cannot
be loaded in the main body trays.
OHP transparencies, tracing paper
2
Note
When using special paper type other than the above mentioned, select
User as paper type in the Bypass tray setting.
7 CAUTION
Do not use paper with staples or paper that conducts electricity (silver,
carbon, etc.)
% An accident may occur as a result of fire.
2
Reminder
To avoid machine trouble, do not use heat-sensitive paper, coloured
OHP transparencies, or paper specifically designed for ink-jet printer,
such as photo-paper.
To Store Copy Paper
Heed the following precautions when storing copy paper.
- Store paper in a cool, dry area. Using damp copy paper may cause a
paper misfeed.
Keep partially used packages tightly wrapped during storage.
- Do not place paper packages vertically to store.
Paper curl due to the vertical storage may cause a paper misfeed.
