3
Paper and Original Information
3-4 bizhub PRO 920
Paper Weight
!
Detail
The paper type setting for trays 1 to 4 is described in "Paper Setting" on
page 15-3.
The paper type setting for Multi-sheet bypass tray is described in
"Copying Using Special Paper (Bypass Tray Setting)" on page 9-16.
See "Loading Tabbed Sheets in Tray" on page 4-10 for loading tabbed
sheets in main body trays and Multi-sheet bypass tray.
2
Reminder
The tray specified as Tab paper cannot be used in duplex copying.
Be sure to load only the paper type specified for that tray such as Thick,
Thin, or Tab paper.
Paper trays Weight
Tray 1, 2, and 3 (Main body trays) 61 to 90 g/m
2
Thick 1: 91 to 170 g/m
2
Thick 2: 171 to 200 g/m
2
Thin: 50 to 60 g/m
2
Tab paper: 91 to 130 g/m
2
Large capacity unit LU-403/404
Multi-sheet bypass tray
Equipment Weight
ADU 61 to 200 g/m
2
Finisher FS-509 50 to 200 g/m
2
Finisher FS-604 60 to 105 g/m
2
+ 200 g/m
2
81 to 105 g/m
2
+ 200 g/m
2
(for Fold&Staple mode only)
Post inserter PI-501 50 to 200 g/m
2
Punch kit PK-504/505 50 to 128 g/m
2
Z folding unit ZU-601/602 60 to 90 g/m
2
Trimmer unit TU-501 60 to 105 g/m
2
+ 200 g/m
2
