Konica Minolta bizhub PRO 920 [57/980] Preparation for use

Preparation for Use

bizhub PRO 920 2-21

No. Name Description

1 Trimmer unit knob Can be turned to ease removal of mishandled pa-

per.

2 Waste basket Holds waste paper cut off from the booklets and

withdrawn for removal of waste paper.

3 Trimmer pressure release lever Opens to allow removal of mishandled paper.
