Basic Job Settings

bizhub PRO 920 9-9

3 Select the desired background adjustment level.

– Touch [Darker] or [Lighter] in the Background Removal area to

move the highlighted indication to the desired adjustment level. Or,

touch [Std.] to resume the standard level.

4 Touch [OK] on the Density/Background adjustment menu.

The Basic Screen will be restored, with the specified exposure level

indicated on the [Density] key.

Note

If no other settings are required, you don’t have to touch [OK] to restore

the Basic Screen. Position originals, then press [Start] to start the printing

job.
