Basic Job Settings

bizhub PRO 920 9-35

8 When all originals are scanned, touch [Complete Scan] to exit the

Separate Scan mode.

9 Press [Start] to print.

All the data in memory will be output.

Reminder

DO NOT press [Reset] with the original already set on the original glass

and duplex copy mode selected, otherwise the Separate Scan mode will

be released to disable the copier from scanning the original placed on the

original glass.

Detail

For the information on unsuitable ADF originals, see "Using Original

Glass" on page 3-11.
