Original Setting

10-20 bizhub PRO 920

5 Touch [Basic] to return to the Basic Screen, then touch [Separate

Scan].

6 Adjust the ADF paper guides.

– Without setting the original,

adjust the ADF paper guides

according to the original size to

be set.

7 Position a sheet of original FACE UP

in the document feeder.

The set original will be automatically

fed and scanned.

8 Touch [Complete Scan] to deselect it and exit the Separate Scan

mode, then press [Start].

The printing job will start.

Reminder

Never set more than one original, otherwise machine trouble may be

caused.
