Finishing / Paper Fold

bizhub PRO 920 12-29

1 Load cover paper into the upper and

lower trays of the post inserter.

2 Use Insert Sheet or Booklet Pagination function to attach covers to the

output copies.

Upper tray

Lower

tray
