Supplies & Handling

bizhub PRO 920 4-19

5 Insert the new staple cartridge into

the cartridge housing.

– Firmly insert the cartridge into the

housing while aligning the arrow

indication on the cartridge

appears as shown below.

6 Remove the lock tape from the

cartridge, then close the bottom of

the housing.

7 Insert the cartridge housing while

sliding it along the stapler rail, then

push down and in to secure it in

place.

8 Return the stacker unit to its original

position.
