Grundfos MAGNA3 D 32-80 180 97924451 [15/1656] Starting up the product

English (GB)

4. Starting up the product

4.1 Single-head pump

Do not start the pump until the system has been filled with liquid

and vented. Furthermore, the required minimum inlet pressure

must be available at the pump inlet. See section 12. Technical

data.

The pump is self-venting through the system, and the system

must be vented at the highest point.

The number of starts and stops via the power

supply must not exceed four times per hour.

Step Action Illustration

Switch on the power supply to the pump.

The pump starts in "AUTO

ADAPT

" mode after

approximately 5 seconds.

TM05 2884 0612

Control panel at first startup.

After a few seconds, the pump display changes to the

startup guide.

TM05 2885 3216

The startup guide guides you through the general settings

of the pump, such as language, date and time.

If you do not touch the buttons on the control panel for 15

minutes, the display goes into sleep mode. When you

touch a button, the "Home" display appears.

TM05 2886 3216

When you have made the general settings, select the

desired control mode or let the pump run in AUTO

ADAPT

mode.

For additional settings, see section 7. Control functions.

TM05 2887 3216

0/Off

1/On
