![Tp-Link T1700G-28TQ V2 [108/772] Stack port info](/views2/1472751/page108/bg6c.png)
Configuration Guide 83
Configuring Stack Stack Configuration
Stack Info
In the Stack Info section, view the stack’s general information.
Stack Topo The stack topology includes Solo, Chain and Ring.
Stack MAC The stack’s MAC address is the MAC address of the stack master.
Stack Member Info
In the Stack Member Info section, view the stack member’s detailed information.
Unit ID The Unit ID of the stack member.
New Unit ID The new Unit ID of the stack member when this stack member or the stack
resets.
Role The current role of this switch, either Master or Member.
MAC Address The MAC address of the switch.
Priority The priority of the stack member. The higher the priority is, the more likely
the stack member is elected as the stack master in the next election.
Version The firmware version of the switch.
State The state of the stack member.
Stack Port Info
In the Stack Port Info section, view the stack port’s detailed information.
Stack Port Displays the ports that can be configured as stack ports.
Stack Port
Group
Displays the group the stack belongs to.
Status Displays whether the port is an Ethernet port or a stack port at the
moment.
Neighbor Displays the stack member the stack port is connected to.
