![Tp-Link T1700G-28TQ V2 [369/772] Unknown multicast pass](/views2/1472751/page369/bg171.png)
Configuration Guide 344
Configuring Layer 2 Multicast Configuring MLD Snooping
3.2.4 Configuring MLD Snooping Parameters on the Port
Configuring Router Port Time and Member Port Time
Step 1 configure
Enter global configuration mode.
Step 2 ipv6 mld snooping rtime
rtime
ipv6 mld snooping mtime
mtime
rtime
is the aging time of router ports, ranging from 60 to 600 seconds.
mtime
is the aging time of member ports, ranging from 60 to 600 seconds.
Step 3 show ipv6 mld snooping
Show the basic MLD snooping configuration.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the global router port time and member
port time as 200 seconds:
Switch#configure
Switch(config)#ipv6 mld snooping
Switch(config)#ipv6 mld snooping rtime 200
Switch(config)#ipv6 mld snooping mtime 200
Switch(config)#show ipv6 mld snooping
MLD Snooping :Enable
Unknown Multicast :Pass
Last Query Times :2
Last Query Interval :1
Global Member Age Time :200
Global Router Age Time :200
Global Report Suppression :Disable
Enable Port:
Enable VLAN:
Switch(config)#end
