Configuration Guide 325
Configuring Layer 2 Multicast IGMP Snooping Configurations
range 226.0.0.5 226.0.0.10
Binding Port(s)
Gi1/0/2
Switch(config)#end
Switch#copy running-config startup-config
2.2.10 Enabling IGMP Accounting and Authentication
Enabling IGMP Authentication on the Port
Step 1 configure
Enter global configuration mode.
Step 2 interface {fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
| port-
channel
port-channel-id
| range port-channe
port-channel-list
}
Enter interface configuration mode
Step 3 ip igmp snooping authentication
Enable IGMP Authentication on the specified port.
Step 4 show ip igmp profile [
id
]
Show the detailed IGMP profile configuration.
Step 6 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable IGMP Authentication on port 1/0/2:
Switch#configure
Switch(config)#ip igmp snooping
Switch(config)#interface gigabitEthernet 1/0/2
Switch(config-if)#ip igmp snooping
Switch(config-if)#ip igmp snooping authentication
Switch(config-if)#show ip igmp snooping interface gigabitEthernet 1/0/2 authentication
Port IGMP-Authentication
---- -------------
Gi1/0/2 enable
