Configuration Guide 534
Configuring ACL ACL Configuration
Step 4
redirect interface { fastEthernet
port
| gigabitEthernet
port
| ten-gigabitEthernet
port
}
(Optional) Define the Policy to redirect the matched packets to the desired port.
port
: The destination port to which the packets will be redirected. The default is All.
s-mirror interface
{ fastEthernet
port
| gigabitEthernet
port
| ten-gigabitEthernet
port
}
(Optional) Define the Policy to mirror the matched packets to the desired port.
port
: The destination port to which the packets will be mirrored
redirect vlan
vlan-id
(Optional) Define the Policy to redirect the matched packets to the desired VLAN.
vlan:
The ID of the VLAN to which the packets will be redirected.
s-condition rate
rate
osd { none | discard }
(Optional) Define the Policy to monitor the rate of the matched packets
rate
: Specify a rate from 1 to 1000000 kbps.
osd:
Select either “none” or “discard” as the action action to be taken for the packets whose
rate is beyond the specified rate. The default is None.
qos-remark dscp
dscp
priority
pri
(Optional) Define the Policy to remark priority for the matched packets.
dscp
: Specify a DSCP for the matched packets between 0 and 63. The default is No Limit.
pri
: Specify a priority for the matched packets between 0 and 3.
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
Create Policy RD, apply ACL 600 to Policy RD, and redirect the matched packets to port 4:
Switch#configure
Switch(config)#access-list policy name RD
Switch(config)#access-list policy action RD 600
Switch(config-action)#redirect interface gigabitEthernet 1/0/4
Switch(config-action)#exit
Switch(config)#show access-list policy RD
