![Tp-Link T1700G-28TQ V2 [66/772] You can create accounts with the access level of operator power user and user here you also need to go to the aaa section to create an enable password for these account...](/views2/1472751/page66/bg42.png)
Managing System User Management Configurations
Configuration Guide
41
Step 3 show user account-list
Verify the information of the current users.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
3.2.2 Creating Accounts of Other Types
You can create accounts with the access level of Operator, Power user and User here. You
also need to go to the AAA section to create an Enable Password for these accounts. The
Enable Password is used to change the users’ access level to Admin.
Follow these steps to create an account of other type:
Step 1 configure
Enter global configuration mode.
