![Tp-Link T1700G-28TQ V2 [365/772] You can search mld static multicast entries by using multicast ip vlan id or forward port as the search option](/views2/1472751/page365/bg16d.png)
Configuration Guide 340
Configuring Layer 2 Multicast Configuring MLD Snooping
Multicast IP Specify the multicast group that the static member is in.
VLAN ID Specify the VLAN that the static member is in.
Forward Port Specify one or more ports to be the static member port in the multicast group.
Without aging, the static member port receives all multicast data sent to this
multicast group.
2) Click Create.
Viewing MLD Static Multicast Groups
You can search MLD static multicast entries by using Multicast IP, VLAN ID or Forward Port
as the Search Option.
Static Multicast IP Table displays details of all MLD static multicast groups.
3.2 Using the CLI
3.2.1 Enabling MLD Snooping Globally
Step 1 configure
Enter global configuration mode.
Step 2 ipv6 mld snooping
Enable MLD Snooping Globally.
Step 3 show ipv6 mld snooping
Show the basic MLD snooping configuration.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
3.2.2 Enabling MLD Snooping on the Port
Step 1 configure
Enter global configuration mode.
Step 2 interface {fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
| ten-gigabitEt
hernet
port |
range ten-gigabitEthernet
port-list |
port-channel
port-channel-id
| range port-channe
port-channel-list
}
Enter interface configuration mode.
