![Tp-Link T1700G-28TQ V2 [533/772] Default settings of voice vlan are listed in the following tables](/views2/1472751/page533/bg215.png)
Configuration Guide 508
Configuring Voice VLAN Appendix: Default Parameters
4
Appendix: Default Parameters
Default settings of voice VLAN are listed in the following tables.
Table 4-1 Default Settings of Global Configuration
Parameter Default Setting
Voice VLAN Disable
VLAN ID None
Aging Time 1440 minutes
Priority 6
Table 4-2 Default Settings of Port Configuration
Parameter Default Setting
Port Mode Auto
Security Mode Disable
Member State Inactive
Table 4-3 Entries in the OUI Table
OUI MASK Description
00-01-e3-00-00-00 ff-ff-ff-00-00-00 Siemens Phone
00-03-6b-00-00-00 ff-ff-ff-00-00-00 Cisco Phone
00-04-0d-00-00-00 ff-ff-ff-00-00-00 Avaya Phone
00-60-b9-00-00-00 ff-ff-ff-00-00-00 Philips Phone
00-d0-1e-00-00-00 ff-ff-ff-00-00-00 Pingtel Phone
00-e0-75-00-00-00 ff-ff-ff-00-00-00 PolyCom Phone
00-e0-bb-00-00-00 ff-ff-ff-00-00-00 3Com Phone
