![Tp-Link T1700G-28TQ V2 [187/772] Switch configure](/views2/1472751/page187/bgbb.png)
Configuration Guide 162
Managing MAC Address Table Address Configurations
Step 2 mac address-table static
mac-addr
vid
vid
interface { gigabitEthernet
port
| ten-
gigabitEthernet
port
}
Bind the MAC address, VLAN and port together to add a static address to the VLAN.
mac-addr
: Enter the MAC address and packets with this destination address received in the
specified VLAN are forwarded to the specified port. The format is xx:xx:xx:xx:xx:xx, for example,
00:00:00:00:00:01.
vid
: Specify an existing VLAN in which packets with the specific MAC address are received.
port:
Specify a port to which packets with the specific MAC address are forwarded. The port
must belong to the specified VLAN.
Step 3 end
Return to privileged EXEC mode.
Step 4 copy running-config startup-config
Save the settings in the configuration file.
Note:
•
In the same VLAN, once an address is configured as a static address, it cannot be set as a filter-
ing address, and vice versa.
•
Multicast or broadcast addresses cannot be set as static addresses.
•
Ports in LAGs (Link Aggregation Group) are not supported for static address configuration.
The following example shows how to add a static MAC address entry with MAC address
00:02:58:4f:6c:23, VLAN 10 and port 1. When a packet is received in VLAN 10 with this
address as its destination, the packet will be forwarded only to port 1.
Switch#configure
Switch(config)# mac address-table static 00:02:58:4f:6c:23 vid 10 interface
gigabitEthernet
1/0/1
Switch(config)#show mac address-table static
MAC Address Table
----------------------------------------------------------------------------
MAC VLAN Port Type Aging
----------------- --- ---- ---- -----
00:02:58:4f:6c:23 10 Gi1/0/1 config static no-aging
Total MAC Addresses for this criterion: 1
Switch(config)#end
