![Tp-Link T1700G-28TQ V2 [556/772] The following example shows how to create extend ip acl 1700 and configure rule7 to deny telnet packets with source ip192 68 00](/views2/1472751/page556/bg22c.png)
Configuring ACL ACL Configuration
Configuration Guide
531
Step 3 access-list extended
acl-id
rule
rule-id
{deny | permit} [ [sip source-ip] smask
source-ip-
mask
] [ [dip
destination-ip
] dmask
destination-ip-mask
] [tseg
time-segment
] [frag {disable
| enable}] [dscp
dscp
] [s-port
s-port
] [d-port
d-port
] [tcpflag
tcpflag
] [protocol
protocol
]
[tos
tos
]
[pre
pr
e]
Add a rule for the ACL.
acl-id:
The ID number of the ACL you have created.
rule-id:
Assign an ID to the rule. It cannot be the same as the existing Extend-IP ACL Rule IDs.
op
:
Specify the action to be taken with the packets that match the rule. Deny means to discard;
permit means to forward. By default, it is set to permit.
source-ip:
Enter the source IP address.
source-ip-mask:
Enter the mask of the source IP address. This is required if a source IP address
is entered.
destination-ip:
Enter the destination IP address.
destination-ip-mask:
Enter the mask of the destination IP address. This is required if a
destination IP address is entered.
time-segment:
The name of the time-range. The default is No Limit.
frag
:
Enable or disable matching of fragmented packets. The default is disable. When enabled,
the rule will apply to all fragmented packets and always permit to forward the last fragment of
a packet.
dscp:
Specify the DSCP value between 0 and 63.
s-port:
Enter the TCP/UDP source port if TCP/UDP protocol is selected.
d-port:
Enter the TCP/UDP destination port if TCP/UDP protocol is selected.
tcpflag:
For TCP protocol, specify the flag value using either binary numbers or * (for example,
01*010*). The default is *, which indicates that the flag will not be matched.
The flags are URG (Urgent flag), ACK (acknowledge flag), PSH(push flag), RST(reset flag),
SYN(synchronize flag), and FIN(finish flag)
protocol:
Specify a protocol type.
tos:
Specify the IP ToS to be matched.
pre:
Specify the IP Precedence to br matched.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to create Extend-IP ACL 1700 and configure Rule7 to
deny Telnet packets with source IP192.168.2.100:
Switch#config
Switch(config)#access-list create 1700
Switch(config)#access-list extended 1700 Rule 7 deny sip 192.168.2.100 smask
255.255.255.255 protocol 6 d-port 23
Switch(config)#show access-list 1700
