Configuring Layer 2 Multicast Configuring MLD Snooping
Configuration Guide
353
3.2.8 Configuring the Querier
Enabling MLD Querier
Step 1 configure
Enter global configuration mode.
Step 2 ipv6 mld snooping querier vlan
vlan-id
vlan-id
specifies the VLAN to enable MLD Querier.
Step 3 show ipv6 mld snooping querier [vlan
vlan-id
]
Show the MLD querier configuration.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable MLD Snooping and MLD Querier in VLAN 4:
Switch#configure
Switch(config)#ipv6 mld snooping
Switch(config)#ipv6 mld snooping querier vlan 4
Switch(config)#show ipv6 mld snooping querier
VLAN 4:
--------------
Maximum Response Time: 10
Query Interval: 60
General Query Source IP: fe80::2ff:ffff:fe00:1
Switch(config)#end
Switch#copy running-config startup-config
Configuring Query Interval, Max Response Time and General Query Source IP
Step 1 configure
Enter global configuration mode.
