![Tp-Link T1700G-28TQ V2 [487/772] Configure the upper rate limit on the port for forwarding broadcast packets multicast packets and unknown unicast frames](/views2/1472751/page487/bg1e7.png)
Configuration Guide 462
Configuring QoS Bandwidth Control Configuration
Step 2 interface {fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
]
Enter interface configuration mode.
Step 3 bandwidth {[ingress
ingress-rate
] [egress
egress-rate
]}
Configure the upper rate limit for the port to receive and send packets.
ingress-rate:
Configure the upper rate limit for receiving packets on the port. The valid values
are from 1 to 1000000 Kbps.
egress-rate:
Configure the upper rate limit for sending packets on the port. The valid values are
from 1 to 1000000 Kbps.
Step 4 show bandwidth {interface [fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range gigabitEthernet
port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
]}
Verify the ingress/egress rate limit for forwarding packets on the port. If no port is specified, it
displays the upper ingress/egress rate limit for all ports.
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the ingress-rate as 5120 Kbps and egress-
rate as 1024 Kbps for port 1/0/5:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/5
Switch(config-if)#bandwidth ingress 5120 egress 1024
Switch(config-if)#show bandwidth interface gigabitEthernet 1/0/5
Port IngressRate(Kbps) EgressRate(Kbps) LAG
--------- ---------------------- ---------------------- ------------
Gi1/0/5 5120 1024 N/A
Switch(config-if)#end
Switch#copy running-config startup-config
3.2.2 Configuring Storm Control
Configure the upper rate limit on the port for forwarding broadcast packets, multicast
packets and unknown unicast frames.
