![Tp-Link T1700G-28TQ V2 [630/772] Switch config line login authentication login1](/views2/1472751/page630/bg276.png)
Configuring Network Security AAA Configuration
Configuration Guide
605
Step 4 enable authentication {
method-list
}
Apply the Enable method list for the application Telnet.
method-list
:
Specify the name of the Enable method list.
Step 5 show aaa global
Verify the configuration of application list.
Step 6 end
Return to privileged EXEC mode.
Step 7 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to apply the existing Login method list named Login1
and Enable method list named Enable1 for the application Telnet.
Switch#configure
Switch(config)#line telnet
Switch(config-line)#login authentication Login1
Switch(config-line)#enable authentication Enable1
Switch(config-line)#show aaa global
......
Module Login List Enable List
Telnet Login1 Enable1
Ssh default default
Http default default
Switch(config-line)#end
Switch#copy running-config startup-config
SSH
Follow these steps to apply the Login and Enable method lists for the application SSH:
Step 1 configure
Enter global configuration mode.
Step 2 line ssh
Enter line configuration mode.
