Managing Physical Interfaces Configuration Examples
Configuration Guide
127
2) Enable loopback detection on ports 1/0/1-3 and set the process mode and recovery
mode.
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#loopback-detection
Switch(config-if)#loopback-detection config process-mode port-based recovery-mode
auto
Switch(config-if)#exit
Switch(config)#interface gigabitEthernet 1/0/2
Switch(config-if)#loopback-detection
Switch(config-if)#loopback-detection config process-mode port-based recovery-mode
auto
Switch(config-if)#exit
Switch(config)#interface gigabitEthernet 1/0/3
Switch(config-if)#loopback-detection
Switch(config-if)#loopback-detection config process-mode port-based recovery-mode
auto
Switch(config-if)#end
Switch#copy running-config startup-config
Verify the Configuration
Verify the global configuration:
Switch#show loopback-detection global
Loopback detection global status : disable
Loopback detection interval: 30 s
Loopback detection recovery time : 3 intervals
Verify the loopback detection configuration on ports:
Switch#show loopback-detection interface
Port Enable Process Mode Recovery Mode Loopback Block LAG
---- ------ ----------------- ------------ ----- ---- -----
Gi1/0/1 enable port-based auto N/A N/A N/A
Gi1/0/2 enable port-based auto N/A N/A N/A
Gi1/0/3 enable port-based auto N/A N/A N/A
