![Tp-Link T1700G-28TQ V2 [56/772] Switch configure](/views2/1472751/page56/bg38.png)
Managing System System Info Configurations
Configuration Guide
31
Specifying the Device Description
Follow these steps to specify the device description:
Step 1 configure
Enter global configuration mode.
Step 2 hostname [
hostname
]
Specify the system name of the switch.
hostname
: Enter the system name. The length of the name ranges from 1 to 32 characters. By
default, it is the model name of the switch.
Step 3 location [
location
]
Specify the system location of the switch.
location
: Enter the device location. It should consist of no more than 32 characters. By default,
it is “SHENZHEN”.
Step 4 contact-info [
contact-info
]
Specify the system contact Information.
contact-info
: Enter the contact information. It should consist of no more than 32 characters. By
default, it is “www.tp-link.com”.
Step 5 show system-info
Verify the system information including system Description, Device Name, Device Location,
System Contact, Hardware Version, Firmware Version, System Time, Run Time and so on.
Step 6 end
Return to privileged EXEC mode.
Step 7 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to set the device name as Switch_A, set the location as
BEIJING and set the contact information as http://www.tp-link.com.
Switch#configure
Switch(config)#hostname Switch_A
Switch(config)#location BEIJING
Switch(config)#contact-info http://www.tp-link.com
Switch(config)#show system-info
System Description - JetStream 24-Port Gigabit Stackable Smart Switch with 4 10GE
SFP+ Slots
System Name - Switch_A
System Location - BEIJING
